GENERAL INFORMATION
Manufacturer: Hewlett-Packard. Proliant
Manufacturer Part Number: 388393-002
Product Name: Proliant 6400 Server.
PROCESSOR & CHIPSET :
Processor Type : Intel Pentium 3 Xeon 500 Mhz .
64-Bit Computing : Yes.
Installed Qty : 2
Max Supported Qty : 4
Data Bus Speed : 100 Mhz
CACHE MEMORY :
Cache Memory Type : L2 Cache – Pipeline Burst.
Installed Size : 2 Mb / 8 Mb (Max)
RAM
Nstalled Size : 256 Mb
Max Supported Qty : 4 Gb
Technology : Edo Ram – Ecc
Access Time : 50 Ns
Form Factor : Dimm 168-Pin
Features : Buffered
Upgrade Rule : 4 Modules At A Time.
STORAGE CONTROLLERS :
Storage Controller Type(1st) : 1 X Scsi – Integrated – Pci.
Controller Interface Type : Ultra Wide Scsi.
Channel Qty : 2
Storage Controller Type(2nd): 1 X Ide – Integrated – Pci.
Controller Interface Type : Ata-33
Channel Qty : 2
STORAGE :
Floppy Drive : 3.5 1.44 Mb Floppy.
Hard Drive : None.
Optical Storage Type : Cd-Rom – Ide.
Read Speed : 24x.
Media Load Type : Tray
DISPLAY & GRAPHICS CONTROLLER :
Graphics Controller Type : Pci – Integrated.
Video Memory : 2 Mb / 2 Mb (Max)
Supported Display Graphics : Vga (640×480), Xga (1024×768), Svga (800×600), Sxga (1280×1024)
Video Output Supported : Rgb
NETWORKING :
Networking : Network Adapter – Pci 64 Hot-Plug – Plug-In Card.
Data Link Protocol : Ethernet, Fast Ethernet. (1000Base)
Compliant Standards : Ieee 802.3, Ieee 802.3u
EXPANSION / CONNECTIVITY :
Expansion Bays Total (Free) :
1 ( 0 ) X Front Accessible – 5.25 X 1/3h
1 ( 0 ) X Front Accessible – 3.5 X 1/3h
4 ( 4 ) X Hot-Swap
EXPANSION SLOTS TOTAL (FREE) :
4 ( 2 ) X Processor – Slot 2
16 ( 12 ) X Memory – Dimm 168-Pin
5 ( 4 ) X Pci 64 Hot Plug
1 ( 1 ) X Shared Pci 64 / Isa
INTERFACES :
1 X Display / Video – Vga – 15 Pin Hd D-Sub (Hd-15)
1 X Keyboard – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Mouse – Generic – 6 Pin Mini-Din (Ps/2 Style)
1 X Serial – Rs-232 – 9 Pin D-Sub (Db-9)
1 X Parallel – Ieee 1284 (Epp/Ecp) – 25 Pin D-Sub (Db-25)
1 X Storage – Ultra Wide Scsi
2 X Network – Ethernet 10base-T/100base-Tx – Rj-45
POWER DEVICE :
Power Device Type : Power Supply – Hot-Plug.
Power Redundancy : Optional.
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
