Manufacturer :CISCO DS HARDWARE DIRECT
Brand :Cisco
Product Line :Cisco Industrial Ethernet
Model :2000 Series
Packaged Quantity :1
RAM
Installed Size :256 megabyte
Flash Memory
Installed Size :64 megabyte, 64 megabyte
Performance
Performance :Forwarding performance (64-byte packet size): 6.5 Mpps
Capacity
Capacity :IGMP groups: 255, Virtual interfaces (VLANs): 255
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :Fast Ethernet
Form Factor :DIN rail mountable
Ports Qty :6
MAC Address Table Size :8K entries
Manageable :Yes
Remote Management Protocol :HTTP, HTTPS, RMON, RMON 2, SNMP 1, SNMP 2, SNMP 3, SSH, Telnet, TFTP
Features :BOOTP support, IGMP snooping, Rapid Spanning Tree Protocol (RSTP) support, Spanning Tree Protocol (STP) support, Syslog support, Uni-Directional Link Detection (UDLD)
Compliant Standards :IEEE 802.11p, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ah, IEEE 802.3x, IEEE 802.3z
Ports
Qty :4
Type :SFP (mini-GBIC)
Ports (2nd)
Qty :2
Type :Gigabit SFP
Expansion Slots
Expansion Slots :1 (total) / 1 (free) x SD Memory Card
Interface Provided
Interfaces :1 x console RJ-45, 1 x mini-USB, 2 x 1000Base-X SFP, 4 x SFP
Software
Type :Cisco IOS LAN Lite
Miscellaneous
Color Category :Black
Encryption Algorithm :SSL
Authentication Method :RADIUS, TACACS+
MTBF :374,052 Hours
Compliant Standards :ANATEL, AS/NZS, BSMI, China RoHS, CISPR 11, CISPR 22 Class A, CISPR 24, CNS 13438(95) Class A, CSA, CSA 22.2 No. 142, CSA C22.2 No. 60950-1, Directive 2011/65/EU, EMC, EMI, EN 50121-3-2, EN 50121-4, EN 60950-1, EN 61000-4-11, EN 61000-4-16, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61131-2, EN 61326-1, EN50155, EN55022 Class A, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-6, IEC 60068-2-60, IEC 60068-2-64, IEC 60945, IEC 60950-1, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-9, IEC 61373, IP30, KCC, KN22 Class A, KN24, NOM-019-SCFI-1998, RoHS 2011/65/EU, UL, UL 508, UL 60950-1, VCCI Class A
Dimensions & Weight
Width :5.1 inch
Depth :3.1 inch
Height :4.5 inch
Weight :2.69 lbs
