Specifications are provided by the manufacturer.
Dimensions & Weight (Shipping)
Shipping Weight :47.49 lbs
Networking
Compliant Standards :IEEE 802.1p, X.509
Connectivity Technology :Wired
Data Link Protocol :10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Data Transfer Rate :10 Gbps
Features :Anti-spam protection, Antivirus analysis, DDos attack prevention, Dead Peer Detection (DPD), DHCP client, DHCP relay, DHCP server, DiffServ Code Point (DSCP) support, DNS proxy, Dynamic DNS server, Equal-Cost Multipath (ECMP), Firewall protection, Front to back airflow, Generic Routing Encapsulation (GRE), High Availability, IGMP filtering, Intrusion Prevention System (IPS), IPSec NAT-Traversal (NAT-T), IPSec Virtual Private Network (VPN), IPv6 support, J-Flow, Label Distribution Protocol (LDP), MPLS support, Multicast Source Discovery Protocol (MSDP), NAT support, Quality of Service (QoS), Source-Specific Multicast (SSM), Virtual Private LAN Service (VPLS), Virtual Route Redundancy Protocol (VRRP) support, VLAN support, VPN support, Weighted Random Early Detection (WRED)
Form Factor :Rack-mountable
Network Transport Protocol :DHCP, IPSec, PPPoE
Ports Qty :8
Remote Management Protocol :SNMP, SSH, Telnet
Routing Protocol :BGP, Bidirectional PIM, IGMP, IGMPv2, IS-IS, OSPF, OSPFv3, RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing
Type :Security appliance
Interface Provided
Connector Type :RJ-45
Qty :1
Type :1000Base-T (management)
Connector Type :SFP
Qty :8
Type :10Gb Ethernet
Connector Type :Type A
Type :USB 2.0
Qty :2
Type :Console
Miscellaneous
Color Category :Gray
Compliant Standards :FCC Class A certified, RoHS2
Encryption Algorithm :128-bit SHA, 256-bit AES, 256-bit SHA, IKE, IKEv2, PKI, SHA-1, Triple DES
Height (Rack Units) :1
MTBF :12 year(s)
Environmental Parameters
Humidity Range Operating :5 – 90% (non-condensing)
Max Operating Temperature :104 °F
Min Operating Temperature :32 °F
Header
Brand :Juniper
Compatibility :PC
Manufacturer :Netscreen
Model :SRX4100 Services Gateway
Packaged Quantity :1
Product Line :Juniper Networks
OS Provided
Type :JUNOS
Power Device
Frequency Required :50/60 Hz
Hot-Plug :Hot-plug
Installed Qty :2
Nominal Voltage :AC 120/230 V
Power Consumption Operational :200 Watt
Power Provided :650 Watt
Power Redundancy :Yes
Type :Internal power supply
Software
Type :Junos Software Enhanced
Storage Hard Drive
Capacity :240 GB
Capacity
Type :Concurrent sessions
Value :5000000
Type :Forwarding table entries
Value :2000000
Type :Routing table entries
Type :Security policies
Value :60000
Performance
Type :Application control (AVC) throughput
Value :18 Gbps
Type :Connection rate
Value :175000 connections per second
Type :Firewall throughput
Value :7 Gbps
Type :Firewall throughput (1518-byte packet size)
Value :40 Gbps
Type :Firewall throughput (64-byte packet size)
Value :5 Gbps
Type :Firewall throughput (IMIX)
Value :20 Gbps
Type :IPS throughput
Type :IPSes throughput (1400-byte packet size)
Value :10 Gbps
Type :VPN throughput (IPSec)
Dimensions & Weight
Depth :25 in
Height :1.7 in
Weight :28.99 lbs
Width :17.5 in
Additional Attributes
C01 category key :548730664735165749
Hard Drive
Installed Qty :2
Type :SSD
RAM
Installed Size :64 GB
